SkyMod® Grid

Designed and engineered by Hacel, the SkyMod Grid offers superior uniform light distribution, energy efficiency and reliability. Combining lighting class semiconductors and converters, the versatile SkyMod Grid is ideally suited to a range of environments.

  • Available in a choice of lumen outputs, delivering up to 8366 lumens
  • Efficacies up to 142 lm/W
  • 21W version has luminance limits below 3000cd/m2 at the 65° cut off in accordance with SLL Code for Lighting 2012
  • Life expectancy in excess of 71,000 hours (L90 B10)
  • IP44 Rated
  • Features an Opal polycarbonate diffuser with wipe clean surface
  • Wireless Lighting Control available, see Connected video for full overview
  • Colour stability within 3 MacAdams
  • Wide choice of high quality control gear
  • 5000K versions, please contact sales for further information
  • TP(b) rated as standard

To Specify:

Use the Code Generator below to select your product specification. Once completed select ‘add to schedule’ to create a schedule of luminaires, your schedule can be found at the top right hand side of the page.

Your product code:

Product specification: SkyMod Grid
