SkyMod Linear Grid

LED

Designed and engineered by Hacel combining lighting class semiconductors and converters, the versatile SkyMod Grid range of luminaires offer superior uniform light distribution, energy efficiency and reliability.


  • Features an Opal polycarbonate diffuser with wipe clean surface
  • Available in a choice of lumen outputs, delivering up to 6920 lumens
  • Efficacies up to 115 lm/W
  • 22W versions has luminance limits below 3000 cd/m² air the 65° cut off *
  • Life expectancy in excess of 60,000 hours (L90 B10)
  • Colour stability within 3 MacAdams
  • Wide choice of high quality control gear
  • 5000K versions, please contact sales for further information
  • TP(b) rated as standard

  • To Specify: Hacel SkyMod Linear Grid LED Panel, 1193 x 293mm Grid Luminaire

    Use the Code Generator below to select your detailed product specification. Once completed, select 'add to schedule', to create a schedule of luminaires, which can be found in the top right hand corner.

    Product Prefix Control Gear Lamp Type Colour Temperature Wattage Product Colour

    Your Product Code:

    Product specification: SkyMod Linear Grid
